Mencom New Tool-Free Inserts

The cabling time of the SQUICH connector can be 50 percent quicker than the screw-type connection and 20 percent quicker than the conventional spring-type connection.

title
title

OAKWOOD, GA — Mencom CSH Series “SQUICH” spring terminal rectangular connectors offer ease of use and cost savings on any harsh manufacturing floors and rugged industrial environments by providing quick-connect solutions for a variety of production machinery.

CSH series “SQUICH” is available in 6, 10, 16, 24, 32 and 48 pole configuration.

The cabling time of the SQUICH connector can be 50 percent quicker than the screw-type connection and 20 percent quicker than the conventional spring-type connection, and CSH connector inserts can be mated with the corresponding inserts of series CNE, CSE, CCE, CTE, CTSE, CN, CT and CSS. They also offer gastight connections to meet the needs found in some hazardous and controlled production environments.

The CSH series “SQUICH” offers:

• Reduced cabling time
• No need for tools
• Quick identification of cabled and non-cabled terminals
• Terminals already opened for conductor clamping
• Possibility to use wires with or without ferrule of up to 2.5mm2
