Since 1841, National Oilwell Varco (NOV) has been dedicated to providing quality and reliable products that work efficiently to drill targeted locations for the oil and gas industry. With over 800 manufacturing, sales and service centers worldwide, NOV prides themselves on meeting industry needs and requirements as quickly as possible. A leader in the design, manufacture and sales of equipment and components used in oil and gas drilling and production, NOV manages several technology solution divisions to keep up with demand in the energy industry.
The NOV facility in Rosenberg, TX manufactures and services downhole drilling motors, which are then transported to oil drilling rigs throughout the region. With over 10,000 SKUs on hand to support manufacturing, the inventory center was nearing capacity and struggling to provide lot tracking information. Taking advantage of a facility relocation, NOV replaced the standard rack and shelving in the inventory center with 2 Shuttle Vertical Lift Modules (VLMs) integrated with pick to light technology and inventory management software from Kardex Remstar. As a result, NOV reduced the size of the inventory center by 82 percent in the new building, is filling orders 64 percent faster and can easily provide lot tracking when necessary.
Automation Frees Up Space For Manufacturing
Previously, racking lined the floor throughout the inventory center, making it difficult and time consuming to find the right components to fill a work order. NOV consolidated 1,800 square feet of inventory in racking into two Shuttle VLMs, occupying only 320 square feet of floor space. Reducing the inventory center floor space required by 82 percent allowed more room for manufacturing and production in the new facility.
Now, two Shuttle VLMs are surrounded by a mezzanine which stores motor casings up right on racks. The VLMs store all component parts required for drill motor production; from internal parts and drill kits to O-rings and seals.
Productivity Is Pumping
The inventory center is responsible for picking and replenishing work orders for manufacturing. Walking up and down the aisles of shelving was a time consuming process. “It was very involved,” says Dennis Moore, Inventory Clerk, “and required lots of walking and searching just to find one part that you needed.”
The VLMs deliver the parts directly to the worker, eliminating walk and search time. This previously wasted time is now spent picking components for work orders. In the old system, three workers were able to fill 25 work orders. The Shuttle VLMs have sped up the process, filling 70 work orders per day, a 64 percent increase in productivity!
Inventory & Lot Control
With parts being stored in open bins, everyone had access to inventory. “Nothing was locked up and it was a free-for-all,” says Moore, “Anyone could go pick anything they wanted, without a way to keep track of it.” The inventory center was responsible for managing and documenting the inventory manually, and that did not always happen. Now with the Shuttle VLMs, all of the inventory is stored in one location and access is limited.
Using the inventory management software, each storage and retrieval transaction is recorded. Further, the operator is directed using pick to light technology to the exact location within the tray to pick or put the part, reducing human picking errors. “Inventory counts are more accurate and mispicks are rare,” says Moore.
The inventory management software is integrated with their ERP system (JD Edwards) to provide the traceability. NOV can now trace the component lot number used in each of their finished drilling motors. If in the event the drill motor malfunctions, NOV can quickly determine what other drilling motor have that same lot number to prevent any potential downtime on other rigs.
Old Methods Get Redirected
Previously, a mechanic would turn in a hand written list of parts that needed to be pulled for an order. The mechanic would bring the paper work order to the inventory center for picking from the rack area. “There was a lot of searching for parts in the rack system,” says Moore. Once the inventory clerk pulled all of the necessary parts, the order was left on a ledge for the mechanic to retrieve.
Mechanics would pick up their work orders from the holding area and bring them to the manufacturing floor for assembly. Once motors are fully assembled, they would be inserted into a steel casing and be placed in another holding area for pickup. Trucks arrive at the facility to load the drill motors and deliver them to an oil rig.
More Efficient Fulfillment
The new process is similar, but the work order fulfillment is much quicker. The work order still originates with the mechanic, who now brings a printed excel sheet to select the parts they need for a given work order. The mechanic now brings the work order to the VLM area for picking. The VLM operator enters the required part numbers into the inventory management software to start the picking process. The VLM retrieves the tray and a TIC (transaction information center) pinpoints the exact location of the required part using pick to light technology.
Trays are delivered to an ergonomic height via an extractor that runs up and down the center of the machine. Operating on the goods to person principle, the operator can now pull the appropriate parts for the work order without having to spend time walking up and down racks searching, bending down and reaching overhead to retrieve the part. Once all parts for the work order have been picked, the inventory clerk delivers the order to the holding table for the mechanic to retrieve.
With the two VLMs, NOV is pulling on average 55 orders per day and 15 orders during the overnight shift. The majority of the work orders are pulled during the day shift in the morning while replenishment occurs overnight. Due to the additional space inside the VLMs, NOV was able to increase inventory on hand by 50 percent.
The Rosenberg facility is not the first NOV location to reap the benefits of automation. NOV has utilized this equipment at other facilities in the area and plans to continue this success in other locations in the future.
The Shuttle VLMs have allowed NOV to increase productivity to meet the demands of their growing industry. The inventory control and tracking abilities enables them to maintain their promise of providing reliable products to their customers.
Kardex Remstar, LLC, a company of the Kardex Group is a leading provider of automated storage and retrieval systems for manufacturing, distribution, warehousing, offices and institutions. For information about our dynamic storage solutions, call 800-639-5805 or visit www.kardexremstar.com.
