When strength, reliability, and corrosion resistance matter most, the right lifting hardware makes all the difference.
Introducing Suncor Stainless’ new line of patented Swivel Hoist Rings — engineered for demanding environments where safety, durability, and performance cannot be compromised.
Designed using premium 316 stainless steel, these hoist rings deliver exceptional strength and long-term performance, maintaining there working load limit at any angle, even in harsh conditions.
316 stainless steel provides outstanding corrosion resistance for applications in marine, clean room, cryogenic, and high-temperature environments.
This premium-grade material also offers an excellent strength-to-weight ratio, making it an ideal solution for lifting applications where durability and reliability are critical.
Features Include:
- Suncor’s patented swivel hoist rings are designed for maximum flexibility and operator safety.
- The ring pivots 180° degrees, allowing loads to align naturally during lifting.
- A 360° rotating base allows for full directional movement, helping operators maneuver loads efficiently — even in confined spaces. The large diameter base supports side loads.
- The wide forged 316 stainless steel ring easily accepts thick crane hooks and is available in both standard and long lengths to accommodate different lifting setups.
- A welded pin design ensures permanent assembly and helps prevent loosening during operation.
- Each assembly includes engraved working load limits and screw torque specifications directly on the part for quick identification and proper installation.
- The addition of a low-friction bronze washer ensures smooth rotation and consistent movement under load.
- The hoist ring is secured with an ASTM F593 high-strength screw, featuring UNC inch threads and available in short or long lengths depending on the application.
- Finally, all swivel components are precision CNC machined from 316 stainless steel, ensuring consistent quality, durability, and reliable performance.
With unmatched versatility, durability, and safety, Suncor Stainless swivel hoist rings provide a dependable lifting solution across a wide range of industries. Built from 100% 316 stainless steel and engineered with a dual self-aligning swivel design, they deliver full working load capacity in any direction.
For more information, visit http://www.suncorstainless.com, email [email protected], or call 800-394-2222.
